Nema 17 Stepper Motor with T8 x 8 Lead Screw - 550mm Linear Guide Slide System for CNC & 3D Printer - STK Series Motion Sliding Table with T-Nut - Perfect for DIY CNC Machines, Laser Cutters, and Automated Manufacturing Equipment

Note:The actual effective length has 10mm longer than the real effective length, which is for protecting the linear guide rail module. If you do not need the additional length, please contact us! We would confirm with you the exact effective length.Product information:Effective length: 50-800MMBall screw: T8 x 2 , T8 x 4, T8 x 8Motor: 42*48 or 57*56 is opcionalScrew pitch (Lead): 2MM/ 4MM/ 8MM optionalThe highest speed: 0-80mm/ s;The package includes Motor 42 (1.5A, 24V) but we also can provide you Motor 57 (3A, 24V). If you have other special requirement, please contact us online.;Package includes : one slide table serie STK + one Stepper Motor

Effective Travel Length 550mm. Stepper motor Nema 17

Repeat positioning accuracy of up to ± 0.1mm

Ball Screws T8x2/ T8x4/ T8x8 are optional,which is for movement structural elements executed, with high precision, high efficiency, long life, low coefficient of friction, versatility, etc

The package includes Motor 42,but we also can provide you Motor 57.If you have special requirement, please contact us.

Widely use equipment such as biotechnology, spraying equipment, punching machine, cutting machine, laser machine, cleaning equipment, welding equipment, packaging machines,DIY, CNC machine
